查看cisco路由器cpu温度 ， 具体命令是什么？show environment all 查看温度
netemu-core1#show environment all
Power Supplies:
Power Supply 1 is Zytek AC Power Supply. Unit is on.
Power Supply 2 is empty.
Temperature readings:
NPE Inletmeasured at 20C/68F
NPE Outletmeasured at 23C/73F
CPU Diemeasured at 39C/102F
Voltage readings:
【思科cp7821使用说明书 思科cpu】+3.30 Vmeasured at +3.26 V
+1.50 Vmeasured at +1.48 V
+2.50 Vmeasured at +2.48 V
+1.80 Vmeasured at +1.79 V
+1.20 Vmeasured at +1.19 V
VDD_CPUmeasured at +1.27 V
VDD_MEMmeasured at +2.46 V
VTTmeasured at +1.24 V
+3.45 Vmeasured at +3.39 V
-11.95measured at -11.89 V
+5.15 Vmeasured at +4.96 V
+12.15 Vmeasured at +12.07 V
Envm stats saved 0 time(s) since reload
你没有使用debug这个命令吧？？
使用这个命令会使cpu占用率增加的 。
其他的话没有这样的命令的哦 ， 可能是你的路由器该换了………………查看思科路由器交换机的硬件状态可以使用：
1、show environment all 查看运行环境
会显示如何内容：
Fan Speed is Normal
Board Temperature:Normal
Internal-ambient temperature=34,Normal
CPU temperature=52,Normal (可以看见处理器温度)
Intake temperature=35,Normal
2、还可以使用如下命令
show environment temperature status
会显示如下内容
Inlet Temperature Value: 26 Degree Celsius
Temperature State: GREEN
Yellow Threshold : 41 Degree Celsius
Red Threshold: 56 Degree Celsius
ASIC Temperature Value: 47 Degree Celsius （可以看这个温度）
Temperature State: GREEN
Yellow Threshold : 105 Degree Celsius
Red Threshold: 125 Degree Celsius
3、还有show environment stack
SWITCH: 1
Switch 1 FAN 1 is OK
Switch 1 FAN 2 is OK
Switch 1 FAN 3 is OK
FAN PS-1 is OK
FAN PS-2 is NOT PRESENT
Switch 1: SYSTEM TEMPERATURE is OK
Inlet Temperature Value: 26 Degree Celsius
Temperature State: GREEN
Yellow Threshold : 41 Degree Celsius
Red Threshold: 56 Degree Celsius
ASIC Temperature Value: 47 Degree Celsius
Temperature State: GREEN
Yellow Threshold : 105 Degree Celsius
Red Threshold: 125 Degree Celsius不懂这问题 ， 给你找到一个连接 ， 希望对你有帮助
?tid=324177

文章插图

大家cisco路由器cpu是哪个牌子的路由器芯片方案 主要翻来覆去就拿几家高通 ， 博通（这家做的最好但是据说不想干了）还有联发科命令式查看cpu历史记录
难道所*号都50%能
2-3使用率
